Fanvil PN1 is a 2-wire converter
Description
Fanvil PN1 is a 2-wire converter featuring a unique design that facilitates the reuse of existing wires. It requires no
cumbersome installation or wiring, simply plug it in and it’s ready to use. This not only saves installation time but also
significantly reduces overall wiring costs. This innovative feature makes PN1 an ideal choice for quick and efficient
deployment in existing infrastructure, providing users with a more convenient and cost-effective experience.
Main Features
Reuse existing wires (PSTN & RVV cables) to save wiring costs Fanvil PN1 2-Wire Converter
Connect any IP device using a 2-wire cable, simplify the wiring process
Compatible with PN8 and PN24 switches for network and power supply, enabling flexible networking
No master-slave distinction between the two PN1 converters.
Maximum transmission distance is up to 1600 meters (Network supply only)
Supports providing POE power to IP devices (Transmission distance is up to 300 meter)
Specifications
Scenario Community, Hotel, Villa, Renovation of an old building
Body ABS
Color Gunmetal
Network Interface RJ45
2-Wire Interface 1
Reset 1
Status Indicator Lights Power indicator light Network indicator light
Power 100-220V~50/60Hz 54V 1.5A
Optional Accessories :
