Technical Spec
Product Dimensions 428×215×431mm(L×W×H)
Net Weight 6 KG
Materials ABS+SPCC+Tempered Glass
Motherboard Support Mini-ITX / Micro-ATX
Front I/O Ports USB3.0×1、Audio×1、TYPE-C×1
3.5′ Drive Bays 2
2.5′ Drive Bays 2+1
Expansion Slots 4 Slots
Pre-Installed Fans Front: 2×140mm ARGB
Rear: 1×120mm ARGB
Fan Support Front: 3×120 / 2×140mm
Top: 2×120 / 2×140mm
Rear: 1×120mm
PSU Shrouded: 2×120mm
Radiator Support Front: 120/140/240/280/360mm
Top: 120/140/240mm
Rear: 120mm
CPU Cooler Height Limit 165mm
GPU Length Limit 320mm
Power Supply Type ATX PS2 （maximum length: 160mm）
Optional Accessories :
CAD-PIXEL-BK, CAD-PIXEL-WH, CAD-PIXEL-GB, CAD-PIXEL-RD, CAD-PIXEL-YE, CAD-PIXEL-BU, CAD-PIXEL-PK, CAD-PIXEL-TV, CAD-PIXEL-GY, CAD-PIXEL-PO
