AMD Ryzen™ Threadripper™ 9960X, 24C/48T, Zen 5, 4.2–5.4 GHz, 350 W, sTR5, DDR5 6400 MT/s, PCIe 5.0, ECC, AES-NI, discrete GPU, Precision Boos,AMD EXPO
General Specifications
Empty heading
Name AMD Ryzen™ Threadripper™ 9960X
Family Ryzen Threadripper
Series Ryzen Threadripper 9000 Series
Form Factor Desktops
Market Segment Enthusiast Desktop
AMD PRO Technologies No
Regional Availability Global
Former Codename Shimada Peak
Processor Architecture Zen 5
# of CPU Cores 24
Multithreading (SMT) Yes
# of Threads 48
Max. Boost Clock Up to 5.4 GHz
Base Clock 4.2 GHz
L1 Cache 1920 KB
L2 Cache 24 MB
L3 Cache 128 MB
Default TDP 350W
Processor Technology for CPU Cores TSMC 4nm FinFET
Processor Technology for I/O Die TSMC 6nm FinFET
Package Die Count 5
Unlocked for Overclocking Yes
AMD EXPO™ Memory Overclocking Technology Yes
Precision Boost Overdrive Yes
Curve Optimizer Voltage Offsets Yes
CPU Socket sTR5
Supporting Chipsets TRX50
CPU Boost Technology Precision Boost 2
Instruction Set x86-64
Supported Extensions AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64
Thermal Solution (PIB) Not Included
Max. Operating Temperature (Tjmax) 95°C
*OS Support Windows 11 – 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit , Windows 10 – 64-Bit Edition
Connectivity
Native USB 3.2 Gen 2 (10Gbps) 4
Native SATA Ports 2
PCI Express® Version PCIe® 5.0
Native PCIe® Lanes (Total/Usable) 92 , 88
NVMe Support Boot , RAID0 , RAID1 , RAID5 , RAID10
System Memory Type DDR5
Memory Channels 4
System Memory Subtype RDIMM
System Memory Specification Up to 6400 MT/s
ECC Support Yes (Default Enabled)
Graphics Capabilities
Graphics Model Discrete Graphics Card Required
Product IDs
Product ID Boxed 100-100001595WOF
Product ID Tray 100-000001595
Manageability
DASH support Yes
Security
AMD Memory Guard Yes
AMD Secure Processor Support Yes
Windows Secure Boot Support Yes
UEFI Secure Boot Support Yes
Windows Device Guard Support Yes
Guest Mode Execution (GMET) Trap Support Yes
Virtualization-Based Security (VBS) Support Yes
Windows Secured-Core PC Support Yes
Firmware TPM Yes
AMD-V (SVM) Support Yes
AMD-V Nested Paging (RVI) Support Yes
AMD AVIC (Interrupt Virtualization) Support Yes
AMD-Vi (I/O MMU Virtualization) Support Yes
Second Level Address Translation (SLAT) Supported Yes
Advanced Encryption Standard New Instructions (AES-NI) Yes
AMD Enhanced Virus Protection (NX bit) Yes
FIPS Certification In Review
Key Features
Supported Technologies AMD EXPO™ Technology , AMD Ryzen™ Technologies
